KOMATSU HAULPAK 830E AC
MINING TRUCK KOMATSU HAULPAK 830E-AC is one large dump truck. Judging from its name, we can determine the specifications of these trucks dunp. Haulpak is a brand of that unit in the manufacturer Komatsu. 830 is the capacity of the units of £ 830,000 or 376 Tons.
ENGINE SPECIFICATION
*Make and model . . . . . . . . . . . . . . . . . . . . . . Komatsu SDA16V160
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Diesel
Number of cylinders. . . . . . . . . . . . . . . . . . . . 16
Operating cycle. . . . . . . . . . . . . . . . . . . . . . . . .4 cycle
**Rated brake power . . . . . . . . . . . 1865 kW 2,500 HP @ 1900 rpm
***Flywheel power . . . . . . . . . . . . . 1761 kW 2,360 HP @ 1900 rpm
Weight (wet) . . . . . . . . . . . . . . . . . . . . . . . . . . . 9608 kg 21,182 lb
* Tier 2 emissions certified. Tier 1 emissions engine is optional outside of North America.
**Rated brake power is the output of the engine as installed in this machine, at governed rpm and with engine manufacturer’s approved fuel setting. Accessory losses included are water pump, fuel pump and oil pump
***Flywheel power is the rated power at the engine flywheel minus the average accessory losses.
Accessories include fan and charging alternator. Rating(s) represent gross engine performance in accordance with SAE J1349 conditions.
ELECTRIC DRIVE
AC/DC CURRENT
Alternator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G.E. GTA-41
Dual impeller in-line blower . . . . . . . . . . . . 255 m /min 9,000 cfm
Control. . . . . . . . . . . . . . . . . . . . . . . . . . AC torque control system
*Motorized wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GEB25
*Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31.875:1
Speed (maximum). . . . . . . . . . . . . . . . . . . . . . . . . 64 kph 40 mph
* Wheel motor application depends upon gross vehicle weight, haul road grade, haul road length, rolling resistance and other parameters. Komatsu and G.E. must analyze each job condition to assure proper application.
ENGINE SPECIFICATION
*Make and model . . . . . . . . . . . . . . . . . . . . . . Komatsu SDA16V160
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Diesel
Number of cylinders. . . . . . . . . . . . . . . . . . . . 16
Operating cycle. . . . . . . . . . . . . . . . . . . . . . . . .4 cycle
**Rated brake power . . . . . . . . . . . 1865 kW 2,500 HP @ 1900 rpm
***Flywheel power . . . . . . . . . . . . . 1761 kW 2,360 HP @ 1900 rpm
Weight (wet) . . . . . . . . . . . . . . . . . . . . . . . . . . . 9608 kg 21,182 lb
* Tier 2 emissions certified. Tier 1 emissions engine is optional outside of North America.
**Rated brake power is the output of the engine as installed in this machine, at governed rpm and with engine manufacturer’s approved fuel setting. Accessory losses included are water pump, fuel pump and oil pump
***Flywheel power is the rated power at the engine flywheel minus the average accessory losses.
Accessories include fan and charging alternator. Rating(s) represent gross engine performance in accordance with SAE J1349 conditions.
ELECTRIC DRIVE
AC/DC CURRENT
Alternator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . G.E. GTA-41
Dual impeller in-line blower . . . . . . . . . . . . 255 m /min 9,000 cfm
Control. . . . . . . . . . . . . . . . . . . . . . . . . . AC torque control system
*Motorized wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GEB25
*Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31.875:1
Speed (maximum). . . . . . . . . . . . . . . . . . . . . . . . . 64 kph 40 mph
* Wheel motor application depends upon gross vehicle weight, haul road grade, haul road length, rolling resistance and other parameters. Komatsu and G.E. must analyze each job condition to assure proper application.
